Heavy Duty Conveyor For Mining And Plant Operations
Details of Heavy Duty Conveyor
Robust Handling Equipment for High-Capacity Transfer
We are manufacturing and exporting heavy-duty conveyors used for transporting bulk materials like coal, aggregates, metal scrap, cement, sugar, grains, and industrial components. These systems are manufactured using structural steel frames, high-tensile rollers, heavy-duty belts or slats, and drive assemblies with planetary gearboxes. Built for rugged use and continuous operation, these conveyors are deployed across demanding environments.
Heavy-duty conveyors are widely used in domestic and industrial sectors such as crushing plants, mining operations, cement factories, fertilizer blending units, foundries, thermal plants, and railway wagon loading systems. These conveyors handle continuous load cycles and high tonnage with reliable operation and minimal downtime.
Long Distance and Harsh Conditions
Built with reinforced channel frames, dust-protected rollers, and industrial-grade gear motors, the system ensures stability and strength under peak loads. Customizable in terms of width, length, incline, and type (belt, chain, slat, roller), these conveyors can operate in abrasive, hot, or outdoor environments with proper guarding and safety features.
Features
- Frame made from MS/SS sections with support legs
- Rubber/PU belts or MS slats based on application
- Direct drive or geared motor with high torque
- Guide rollers and take-up systems included
- Optional loading hoppers and discharge chutes
Application
These conveyors are largely used in domestic and industrial sectors, such as:
- Stone crushing and sand screening plants
- Cement bag loading and clinker transport lines
- Scrap movement in steel melting shops
- Granular fertilizer and powder bagging sections
- Grain depots, ports, and warehouse feed zones
Specification
| Parameter | Description |
|---|---|
| Conveyor Type | Belt / Slat / Roller / Chain |
| Load Capacity | Up to 5000 kg/hr (customizable) |
| Width Options | 300 mm to 1500 mm |
| Length Range | 2 m to 50 m or more |
| Frame Material | MS / SS / Powder Coated |
| Drive Mechanism | Gearbox Drive / Motorized Pulley |
| Inclination | Horizontal / Inclined / Z-Frame |
| Optional Add-ons | Side guards, bins, scrapers |
Our heavy-duty conveyors are widely installed in Raipur, Jamshedpur, Surat, Bhiwadi, Nagpur, and also exported to Kenya, the UAE, and Bangladesh. Known for long service life, rugged frames, and quick installation, these units support non-stop material handling in time-sensitive operations.
Enquiry & System Assistance
We, as a company, are manufacturing heavy-duty conveyors for continuous duty applications with custom engineering, load-tested designs, and upgrade support. In addition to our commitment to quality and customer satisfaction, we offer layout drafting, site assistance, and preventive maintenance guidance. Project contractors, civil engineers, and plant heads may contact us for sizing, configurations, and dispatch.
